Nominal Power 7,8kW Efficiency 80,7% CO(%) (13% O2) 0,085 NOx | COV | Particles 112 | 85 | 36mg/m3 Gas Temperature 245ºC Control – Ventilation – Wood Size 450mm Chimney Diameter Ø 150mm Weight 170Kg Dimensions (HxWxD) 965x750x410mm
-
Nominal Power 7,8kW Efficiency 80,7% CO(%) (13% O2) 0,085 NOx | COV | Particles 112 | 85 | 36mg/m3 Gas Temperature 245ºC Control – Ventilation – Wood Size 450mm Chimney Diameter Ø 150mm Weight 130Kg Dimensions (HxWxD) 1020x750x410mm
-
Nominal Power 6,6kW Efficiency 80% CO(%) (13% O2) 0,11 Gas Temperature 257ºC NOx | COV | Particles 93 | 55 | 7mg/m3 Control - Ventilation - Wood Size 400mm Chimney Diameter Ø 120mm Weight 82Kg Dimensions (HxWxD) 675x530x310mm
-
Nominal Power 9,6kW Efficiency 90% Heating area 235m3 NOx | COV | Particles 137 | 2 | 4mg/m3 Emissões de CO (13% O2) 0,013% Pellet Consumption (Min-Max) 0,76~2,16Kg/h Capacity Deposit Pellets 15Kg Chimney Diameter Ø 80mm Weight 89Kg Dimensions (HxWxD) 1010x480x550mm
-
Nominal Power 9,6kW Efficiency 90% Heating area 235m3 NOx | COV | Particles 137 | 2 | 4mg/m3 Emissões de CO (13% O2) 0,013% Pellet Consumption (Min-Max) 0,76~2,16Kg/h Capacity Deposit Pellets 15Kg Chimney Diameter Ø 80mm Weight 89Kg Dimensions (HxWxD) 1010x480x550mm
-
Nominal Power 7,8kW Efficiency 80,7% CO(%) (13% O2) 0,085 Gas Temperature 245ºC NOx | COV | Particles 112 | 85 | 36mg/m3 Control – Ventilation – Wood Size 450mm Chimney Diameter Ø 150mm Weight 95kg Dimensions (HxWxD) 704x735x435mm
-
Nominal Power 11,8kW Efficiency 87,4% Compartment Power 3,9kW Power delivered to water 7,9kW CO(%) (13% O2) 0,094 Gas Temperature 161ºC NOx | COV | Particles 120| 31 | 30/m3 Wood Size 350mm Chimney Diameter Ø 150mm Weight 240Kg Dimensions (HxWxD) 950x884x731m
-
Nominal Power 12kW Efficiency 78% CO(%) (13% O2) 0,063 Gas Temperature 222ºC NOx | COV | Particles 82 | 39 | 35mg/m3 Control - Ventilation - Wood Size 500mm Chimney Diameter Ø 200mm Weight 324Kg Dimensions (HxWxD) 1871x1041x670mm
-
Nominal Power 12kW Efficiency 78% CO(%) (13% O2) 0,091 Gas Temperature 239ºC NOx | COV | Particles 98 | 69 | 38mg/m3 Control - Ventilation - Wood Size 500mm Chimney Diameter Ø 200mm Weight 384Kg Dimensions (HxWxD) 1897x777x1115mm
-
Nominal Power 6kW Efficiency 82,3% CO(%) (13% O2) 0,063 NOx | COV | Particles 98 | 116 | 21 mg/m3 Gas Temperature 231ºC Control Termoclik 50ºC Ventilation 340m3 Wood Size 320mm Chimney Diameter Ø 120mm Weight 89Kg Dimensions (HxWxD) 806x595x605mm
-
Nominal Power 5,5kW Efficiency 83,9% CO(%) (13% O2) 0,041 NOx | COV | Particles 152 | 24 | 35mg/m3 Control Termoclik 50ºC Ventilation 340m3 Wood Size 320mm Chimney Diameter Ø 120mm Weight 83Kg Dimensions (HxWxD) 810x477x376mm
-
Nominal Power 7,8kW Efficiency 80,7% CO(%) (13% O2) 0,085 NOx | COV | Particles 112 | 85 | 36mg/m3 Gas Temperature 245ºC Control – Ventilation – Wood Size 450mm Chimney Diameter Ø 150mm Weight 105Kg Dimensions (HxWxD) 704x735x435mm
-
Nominal Power 7,8kW Efficiency 80,7% CO(%) (13% O2) 0,085 NOx | COV | Particles 112 | 85 | 36mg/m3 Gas Temperature 245ºC Control – Ventilation – Wood Size 450mm Chimney Diameter Ø 150mm Weight 95Kg Dimensions (HxWxD) 704x735x435mm
-
Nominal Power 10,6kW Efficiency 87,3% CO(%) (13% O2) 0,013 NOx | COV | Particles 106 | 3 | 14mg/m3 Gas Temperature 255ºC Heating area 260m3 Pellet Consumption (Min-Max) 0,95~2,5Kg/h Capacity Deposit Pellets 15Kg Chimney Diameter Ø 80mm Weight 120Kg Dimensions (HxWxD) 885x800x281mm
-
Nominal Power 26,2kW Efficiency 90,4% Power delivered to water 21,7kW Boiler Water Capacity 55L Heating area 640m3 Máx. Hot Water in the Boiler 90ºC NOx | COV | Particles 148 | 2 | 19mg/m3 Emissões de CO (13% O2) 0,01 Capacity Deposit Pellets 25Kg Chimney Diameter Ø 100mm Weight 190Kg Dimensions (HxWxD) 1160x985x400mm
-
Nominal Power 20kW Efficiency 93% Power delivered to water 16,7kW Boiler Water Capacity 50L Heating area 490m3 Máx. Hot Water in the Boiler 90ºC NOx | COV | Particles 127 | 1 | 15mg/m3 Emissões de CO (13% O2) 0,012 Capacity Deposit Pellets 22Kg Chimney Diameter Ø 80mm Weight 180Kg Dimensions (HxWxD) 1140x935x390mm
-
Nominal Power 10kW Efficiency 90,2% Heating area 225m3 NOx | COV | Particles 146 | 2 | 20mg/m3 Emissões de CO (13% O2) 0,003 Pellet Consumption (Min-Max) 0,9~2,26Kg/h Capacity Deposit Pellets 15Kg Chimney Diameter Ø 80mm Weight 95Kg Dimensions (HxWxD) 1105x820x290mm
-
Nominal Power 6kW Efficiency 82,3% CO(%) (13% O2) 0,063 Gas Temperature 231ºC NOx | COV | Particles 98 | 116 | 21 mg/m3 Control - Ventilation - Wood Size 320mm Chimney Diameter Ø 120mm Weight 73Kg Dimensions (HxWxD) 710x623x610mm
-
Nominal Power 5kW Efficiency 80,5% CO(%) (13% O2) 0,1 NOx | COV | Particles 115 | 61 | 15 mg/m3 Gas Temperature 288ºC Control – Ventilation – Wood Size 300mm Chimney Diameter Ø 150mm Weight 71Kg Dimensions (HxWxD) 550x488x358mm
-
Nominal Power 7,8kW Efficiency 80,7% CO(%) (13% O2) 0,085 Gas Temperature 245ºC NOx | COV | Particles 112 | 85 | 36mg/m3 Control Termoclik 50ºC Ventilation 132m3 Wood Size 450mm Chimney Diameter Ø 150mm Weight 100Kg Dimensions (HxWxD) 545x685x440mm
-
Nominal Power 6,5kW Efficiency 75,3% CO(%) (13% O2) 0,085 Gas Temperature 264ºC NOx | COV | Particles 114 | 70 | 29mg/m3 Control Termoclik 50ºC Ventilation 132m3 Wood Size 420mm Chimney Diameter Ø 150mm Weight 85Kg Dimensions (HxWxD) 540x600x440mm
-
Nominal Power 19kW Efficiency 81% CO(%) (13% O2) 0,096 Gas Temperature 315ºC NOx | COV | Particles 90 | 43 | 29mg/m3 Control - Ventilation - Wood Size 600mm Chimney Diameter Ø 220mm Weight 275Kg Dimensions (HxWxD) 1324x1124x655mm
-
Nominal Power 14kW Efficiency 83% CO(%) (13% O2) 0,068 Gas Temperature 241ºC NOx | COV | Particles 94 | 25 | 32mg/m3 Control - Ventilation - Wood Size 450mm Chimney Diameter Ø 200mm Weight 215Kg Dimensions (HxWxD) 1231x904x655mm
-
Nominal Power 40kW Efficiency 90,6% Water Volume 124L Pressão Máxima 3bar Gas Temperature 130ºC NOx | COV | Particles 190 | 25 | 24mg/m3 CO(%) (13% O2) 0,016 Temperatura máxima de trabalho 90ºC Capacity Deposit Pellets ~200Kg Comprimento Máx da Lenha 330mm Chimney Diameter Ø 180mm Weight 530Kg Dimensions (HxWxD) 1415x1306x955mm
-
Nominal Power 30kW Efficiency 90,9% Water Volume 87L Pressão Máxima 3bar Gas Temperature 131ºC NOx | COV | Particles 189 | 17 | 28mg/m3 CO(%) (13% O2) 0,012 Temperatura máxima de trabalho 90ºC Capacity Deposit Pellets ~200Kg Comprimento Máx da Lenha 330mm Chimney Diameter Ø 180mm Weight 510Kg Dimensions (HxWxD) 1415x1256x955mm
-
Nominal Power 40,18kW Efficiency 93,07% Power delivered to water 40,18kW Boiler Water Capacity 140L Máx. Hot Water in the Boiler 90ºC Gas Temperature 129ºC NOx | COV | Particles 188 | 7 | 8mg/m3 CO(%) (13% O2) 0,014 Wood Size 500mm Chimney Diameter Ø 150mm Weight 450Kg Dimensions (HxWxD) 1387x663x1255mm
-
Nominal Power 22,67kW Efficiency 91,8% Power delivered to water 22,67kW Boiler Water Capacity 120L Máx. Hot Water in the Boiler 90ºC Gas Temperature 161ºC NOx | COV | Particles 176 | 11 | 12mg/m3 CO(%) (13% O2) 0,012 Wood Size 500mm Chimney Diameter Ø 150mm Weight 429Kg Dimensions (HxWxD) 1387x663x1135mm
-
Nominal Power 31,7kW Efficiency 92,3% Water Volume 50L Power delivered to water 31,7kW CO(%) (13% O2) 0,009 NOx | COV | Particles 158 | 3 | 10mg/m3 Heating area 779m3 Máx. Hot Water in the Boiler 90ºC Pellet Consumption (Min-Max) 2,1~7Kg/h Capacity Deposit Pellets 70Kg Chimney Diameter Ø 100mm Weight 330Kg Dimensions (HxWxD) 1390x665x820mm
-
Nominal Power 25,5kW Efficiency 91,7% Water Volume 35L Power delivered to water 25,5kW CO(%) (13% O2) 0,010 NOx | COV | Particles 160 | 3 | 11mg/m3 Heating area 626m3 Máx. Hot Water in the Boiler 90ºC Pellet Consumption (Min-Max) 2,1~5,7Kg/h Capacity Deposit Pellets 50Kg Chimney Diameter Ø 100mm Weight 265Kg Dimensions (HxWxD) 1290x605x875mm
-
Nominal Power 11kW Efficiency 87,6% CO(%) (13% O2) 0,007 NOx | COV | Particles 109 | 1 | 20mg/m3 Gas Temperature 264ºC Heating area 270m3 Pellet Consumption (Min-Max) 0,8~2,6Kg/h Capacity Deposit Pellets 20Kg Chimney Diameter Ø 80mm Weight 120Kg Dimensions (HxWxD) 973x530x530mm
-
Nominal Power 8,9kW Efficiency 81% CO(%) (13% O2) 0,12 Gas Temperature 179ºC NOx | COV | Particles 68 | 113| 22mg/m3 Control – Ventilation – Wood Size 400mm Chimney Diameter Ø 150mm Weight 128kg Dimensions (HxWxD) 825x830x535mm Oven Dimensions (HxWxD) 280x370x470mm Furnace Dimensions (HxWxD) 300x200x470mm
-
Nominal Power 8,9kW Efficiency 81% CO(%) (13% O2) 0,12 Gas Temperature 179ºC NOx | COV | Particles 68 | 113| 22mg/m3 Control – Ventilation – Wood Size 400mm Chimney Diameter Ø 150mm Weight 143kg Dimensions (HxWxD) 825x830x535mm Oven Dimensions (HxWxD) 280x370x470mm Furnace Dimensions (HxWxD) 300x200x470mm
-
Nominal Power 8,9kW Efficiency 81% CO(%) (13% O2) 0,12 Gas Temperature 179ºC NOx | COV | Particles 68 | 113| 22mg/m3 Control – Ventilation – Wood Size 400mm Chimney Diameter Ø 150mm Weight 160kg Dimensions (HxWxD) 825x935x535mm Oven Dimensions (HxWxD) 280x370x470mm Furnace Dimensions (HxWxD) 300x200x470mm
-
Nominal Power 6,8kW Efficiency 83% CO(%) (13% O2) 0,10 Gas Temperature 177ºC NOx | COV | Particles 91 | 18 | 8mg/m3 Control – Ventilation – Wood Size 400mm Chimney Diameter Ø 150mm Weight 130kg Dimensions (HxWxD) 820x935x545mm Oven Dimensions (HxWxD) 280x415x460mm Furnace Dimensions (HxWxD) 320x220x440mm
-
Nominal Power 6,8kW Efficiency 83% CO(%) (13% O2) 0,10 Gas Temperature 177ºC NOx | COV | Particles 91 | 18 | 8mg/m3 Control – Ventilation – Wood Size 400mm Chimney Diameter Ø 150mm Weight 130kg Dimensions (HxWxD) 820x935x545mm Oven Dimensions (HxWxD) 280x415x460mm Furnace Dimensions (HxWxD) 320x220x440mm
-
Nominal Power 6,8kW Efficiency 83% CO(%) (13% O2) 0,10 Gas Temperature 177ºC NOx | COV | Particles 91 | 18 | 8mg/m3 Control – Ventilation – Wood Size 400mm Chimney Diameter Ø 150mm Weight 130kg Dimensions (HxWxD) 820x935x545mm Oven Dimensions (HxWxD) 280x415x460mm Furnace Dimensions (HxWxD) 320x220x440mm
